Peddinghaus PCD1100/3B 3-Spindle Beam Drill With Ocean DCM 20/30 Miter Saw & Material Handling
Model:
PCD1100/3B
Age:
2013
Ref#:
44158
Prestige Equipment is the world's leading provider of Peddinghaus PCD1100/3B 3-Spindle Beam Drill With Ocean DCM 20/30 Miter Saw & Material Handling & machine tools & fabricating equipment. Take a look at our wide selection of new and used CNC Beam Drill Lines for sale.
Product Specifications
Features:
✓
Siemens CNC Control
✓
Ocean Terminator DCM-20/30 Horizontal Miter Band Saw
✓
Material Handling
Product Specifications
CAPACITY:
Maximum Machining Width
43.31"
Maximum Machining Height
18"
Minimum Machining Width
3"
Minimum Length Piece Part
62"
Minimum Bar Stock Thickness
3/4"
Number of Drill Spindles
3
Drill Diameter
1-9/16"
Power per Spindle
13.5 HP
Spindle Speeds
200 - 850 RPM
Spindle Stroke
13"
Positioning Stroke on Flange Drills
0 - 18"
Positioning Stroke on Web Drill
0 - 43.31"
X-Axis Feed
130 FPM
Maximum Work Piece Weight
18,000 Lbs
Equipped With:
Siemens CNC Control
Unist MQL
28'of 36" Idler Roller Conveyor (Custom Fabricated)
53' of 36" Powered Roller Conveyor (Custom Fabricated)
(4) 14' Lift & Carry Transfers (Custom Fabricated)
Ocean Terminator DCM-20/30 (20" x 30" Cap.) Horizontal Miter Band Saw (2008)
NOTE:
Inspect in a Plant Under Power
Features:
✓
Siemens CNC Control
✓
Ocean Terminator DCM-20/30 Horizontal Miter Band Saw
✓
Material Handling
