YCM DCV 4025B CNC BRIDGE TYPE MACHINING CENTER
Model:
DCV 4025B
Age:
2008
Ref#:
45036
Prestige Equipment is the world's leading provider of YCM DCV 4025B CNC BRIDGE TYPE MACHINING CENTER & machine tools & fabricating equipment. Take a look at our wide selection of new and used CNC Bridge Type Vertical Machining Centers (VMC) for sale.
Product Specifications
Features:
✓
FANUC 18iMB CNC CONTROLS
✓
120-STATION AUTOMATIC TOOL CHANGER
✓
ETHERNET
✓
HIGH SPEED MACHINING
✓
DATA SERVER
✓
SPINDLE THERMAL COMPENSATION
✓
COOLANT THROUGH SPINDLE
✓
3 ROLLER TYPE GUIDE WAY FOR Y AXIS
✓
HARDENED AND GROUND BOX WAY Z AXIS
✓
CHILLER UNIT
✓
CHIP CONVEYOR
Product Specifications
SPECIFICATIONS:
TABLE SIZE............................. 158" x 94.5"
158" x 94.5"
TABLE WEIGHT CAPACITY
44,092 LBS.
LONGITUDINAL TRAVEL, X-Axis............ 160"
160"
CROSS TRAVEL, Y-Axis
98"
RAM STROKE, Z-Axis
40"
FEED RATE X, Y, Z
472/591/591 IPM
CUTTING FEED RATE
0.04~394 IPM
SPINDLE SPEEDS......................... 10,000 RPM
10,000 RPM
SPINDLE DRIVE.......................... 25/30 HP (18.5/22 kw)
25/30 HP (18.5/22 kw)
SPINDLE TAPER.......................... CAT 50
CAT 50
TOOL CHANGER
120 ATC
DISTANCE BETWEENS COLUMNS.............. 107.9"
107.9"
MAX. TOOL WEIGHT
44.1 Lbs.
MAX. TOOL DIMENSIONS
4.92" x 13.78"
DISTANCE SPINDLE NOSE & TAPLE TOP
7.87~47.87"
MACHINE Weight
101,412 Lbs.
MACHINE ELECTRICS
220/480
Equipped With:
FANUC 18iMB CNC CONTROLS
120-STATION AUTOMATIC TOOL CHANGER
ETHERNET
HIGH SPEED MACHINING
DATA SERVER
SPINDLE THERMAL COMPENSATION
COOLANT THROUGH SPINDLE
3 ROLLER TYPE GUIDE WAY FOR Y AXIS
HARDENED AND GROUND BOX WAY Z AXIS
CHILLER UNIT
CHIP CONVEYOR
Features:
✓
FANUC 18iMB CNC CONTROLS
✓
120-STATION AUTOMATIC TOOL CHANGER
✓
ETHERNET
✓
HIGH SPEED MACHINING
✓
DATA SERVER
✓
SPINDLE THERMAL COMPENSATION
✓
COOLANT THROUGH SPINDLE
✓
3 ROLLER TYPE GUIDE WAY FOR Y AXIS
✓
HARDENED AND GROUND BOX WAY Z AXIS
✓
CHILLER UNIT
✓
CHIP CONVEYOR
