Salvagnini 242 Ton x 3.96 M 7-Axis B3-220/4250 CNC Hydraulic Press Brake, (2) Available

Model:
B3 ATA B3.220-4250
Age:
2014
Ref#:
31786
View Video
Prestige Equipment is the world's leading provider of Salvagnini 242 Ton x 3.96 M 7-Axis B3-220/4250 CNC Hydraulic Press Brake, (2) Available & machine tools & fabricating equipment. Take a look at our wide selection of new and used Hydraulic Press Brakes for sale.
Product Specifications
Features:
Salvagnini 7-Axis CNC Control With Graphic Display
5-Axis BG7 CNC Back Gauge
Automatic Upper Tool Adjuster (ATA)
Adaptive Crowning
Wila "New Standard" Hydraulic Upper & Lower Clamping
Product Specifications
CAPACITY:
Maximum Tonnage Capacity
242 Ton
Overall Length Of Bed & Ram
4250 MM
Distance Between Housings
3620 MM
Throat Depth
520 MM
Stroke Length
450 MM
Maximum Speed
13200 MM/MIN
Bending Speed
1080 MM/MIN
Main Motor
26 KW
Approximate Dimensions (LxWxH)
5329 MM x 2078 MM x 3706 MM
Approximate Shipping Weight
23859 KG .
Equipped With:
Salvagnini 7-Axis CNC Control With Graphic Display
5-Axis BG7 CNC Back Gauge (X1,X2,Z1,Z2,R)
Adaptive Crowning
Wila Hydraulic Power Upper & Lower Clamping
Automatic Tool Adjuster (ATA) for automatically adjusting upper bending tool length
Heat Exchanger Assembled On The Electric Cabinet
Angle Measurement System (AMS)
MVM Option (Programmable Lower Die Rail)
Fast Bend Safety System With Automatic Height
Oil Cooling Unit
Tool Opening Via Control Console With Foot Switch
Electric Foot Switch
Lazer Safety Light Guarding
Wila New Standard Tooling System with Machine
Flush Floor
NOTE:
This machine can be inspected under power in our Philadelphia Warehouse.
There are two machines available
