Toshiba TSS30/55A 118" /216" Openside Vertical Boring Mill
Model:
TSS30/55 Openside
Age:
N/A
Ref#:
31310
Prestige Equipment is the world's leading provider of Toshiba TSS30/55A 118" /216" Openside Vertical Boring Mill & machine tools & fabricating equipment. Take a look at our wide selection of new and used Manual Vertical Boring Mills (VBM) for sale.
Product Specifications
Features:
✓
Full Pendant Control w/ Joystick
✓
118" Face Plate Type Chuck with 4-Top Jaws
✓
Threading
✓
Digital Readout
✓
Operator Platform
✓
Variable Speed Table
✓
Table on Infeed Slide for extended travel
✓
Hydraulic Table Positioning
✓
85 HP (63 KW) Main Motor
Product Specifications
CAPACITY:
Table Diameter
118"
Maximum Swing
216.5"
Maximum Swing For Center Turn
157"
Maximum Height Under Rail
109.6"
Height Under Tool
102.4"
Cross Rail Travel
53"
Ram Stroke
49"
Ram Tilt (+/-)
+/- 30 Degrees
Table Speeds (16)
1.25-80 RPM
Feeds
.0008-.8 IPR
Threading Range:
Threading Range , Metric
1-16 mm
Machine Footprint
335" x 260"
Machine Height
268"
Machine Net Weight
75,000 lbs
Equipped With:
Full pendant Control w/ Joystick
118" Face Plate Type Chuck with 4-Top Jaws
Threading
Digital Readout
Operator Platform
Variable Speed Table
Table on Infeed Slide for extended travel
Hydraulic Table Positioning
85 HP (63 KW) Main Motor
Note:
Inspect Under Power!
Offer includes Disassembly and Loading to Trucks!
Features:
✓
Full Pendant Control w/ Joystick
✓
118" Face Plate Type Chuck with 4-Top Jaws
✓
Threading
✓
Digital Readout
✓
Operator Platform
✓
Variable Speed Table
✓
Table on Infeed Slide for extended travel
✓
Hydraulic Table Positioning
✓
85 HP (63 KW) Main Motor
