Doosan Lynx 220LMA CNC Turning Center with Live Milling

Model:
Lynx 220LMA
Age:
2007
Ref#:
43296
Prestige Equipment is the world's leading provider of Doosan Lynx 220LMA CNC Turning Center with Live Milling & machine tools & fabricating equipment. Take a look at our wide selection of new and used Three Axis Or More CNC Lathes for sale.
Product Specifications
Features:
Fanuc 0i-TC Series CNC Control
12/24-Position Turret
Live Milling & C-Axis
Part Catcher
Tailstock
Product Specifications
CAPACITIES:
Swing Over Bed
511 MM
Swing Over Saddle
290 MM
Max. Turning Diameter
249 MM
Distance Between Centers
511 MM
Max. Turning Length
511 MM
Chuck Capacity
152 MM
Bar Capacity
51 MM
X-Axis Travel
175 MM
Z-Axis Travel
551 MM
Spindle Speed
6000 RPM
Spindle Motor
15 KW /11 KW
Spindle Nose
A2-5
Number of Tool Stations
12
Number of Indexing Stations
24
Rotary Tool Speed
6000 RPM
Rotary Tool Motor
4 KW
Tailstock Quill Diameter
66 MM
Tailstock Quill Bore Taper
MT #4
Tailstock Quill Travel
79 MM
Rapid Traverse, X-Axis
29997 MM/MIN
Rapid Traverse, Z-Axis
35992 MM/MIN
Cutting Feed Rate
500 MM/MIN
Machine Dimensions
2629 MM x 1600 MM x 1656 MM
Approximate Machine Weight
1497 KG .
Equipped With:
Fanuc 0i-TC Series CNC Control
12/24-Position Turret
Live Milling & C-Axis
Part Catcher
Tool Eye
Tailstock
Turbo Chip Conveyor
Features:
Fanuc 0i-TC Series CNC Control
12/24-Position Turret
Live Milling & C-Axis
Part Catcher
Tailstock
