Worldwide Industrial Auctions & Liquidations
Onsite & Online Auction
Former Assets of Trident Metals
(4) Wohlenberg CNC Counter Rotating Deep Hole Boring Machines, (4) SHW Traveling Column CNC HMCs, CNC Lathes, CNC Hollow Spindle Lathes, VMCs, Vertical Turret Mill, Table Type HBMs, Horizontal Band Saws, Inspection, Shop & Warehouse Equipment, Material Handling
April 5, 2017
10:00AM CST
Katy, TX
View Brochure Share Print
Contact for Sale
Adam Herman
Email Me
631-249-5566
Inspection Date
April 4, 2017
9:00AM - 4:00PM CDT
In Conjunction With
Prestige Auctions
Featured Assets

CNC COUNTER ROTATING DEEP HOLE BORING MACHINES

  • (4) WOHLENBERG MDL. PB2-1000B, Fanuc 21i-TB CNC control, rack drive design, 39.37” swing over bed, 157″ max. boring depth, 100 KW headstock, 100 KW drill drive motor, 24-3/4″ 3-jaw chuck, (2) manual damper rests, chip conveyor & swarf system, paper filter separator, Koolant Koolers coolant refrigeration system, 3,000 LPM cap. coolant system, 15′ x 6′ x 6′ above ground coolant storage tank, S/N D4584 new 2006 (currently installed) S/N D4602, S/N D4603, S/N D4604 – these machines were built in 2008, are unused & were never installed

BORING MACHINE TOOLING

  • BORING BARS, including: 6-1/2″, 5-1/2″, 5″, 4-1/2″, 4″, 3-1/2″, 3″, (2) 2-3/4″, 2-1/2″, (2) 2″ & 1-3/4″; WIDE SELECTION CUTTER HEADS, SLEEVES, DAMPERS, PRESSURE HEADS, & LANTERN CHUCK

TRAVELLING COLUMN CNC HORIZONTAL MACHINING CENTERS

  • (4) SHW MDL. POWER SPEED 5, new 2007, Heidenhain TNC530 CNC control, 39.37” x 354.3” T-slotted work table, 314.96” X, 63” Y, 51” Z-axis travels, 1181 IPM rapids, 360 deg C axis head swivel, 180 deg. A axis head swivel, CAT-50 spdl. taper, spdl. spds: 36-6000 RPM, 45 KW spdl. drive motor, 90 pos. ATC, Roll Work Holding & Rotation System Including: FIBRO CNC B-axis vert. rotary table w/13.77” thru hole, 27.5″ center height, 5500 lb. max. rotary table cap., 27.5” 4-jaw chuck, (3) Autoblock hyd. Steady rests, 3.93” to 13.77” cap., probe system, (1) manual support rest, scale feedback system, roller chip shields, S/N 5236, S/N 5237, S/N 5238, S/N 5239

CNC COMBINATION VERTICAL TURNING AND MACHINING CENTER (MILLTURN)

  • DORRIES SCHARMANN MDL. SOLON 3/DS, Siemens 840 CNC control, 49.6” pallet dia., 4400 lb. max. pallet weight, 61.02″ max. working height, 59” X-axis travel, 47.2” Y-axis travel, 49.6” Z-axis travel, contouring B-axis rotary table, milling spdl. spds: 73-4000 RPM, CAT-50 spdl. taper, 45 KW milling spdl., turning table spds: 1-500 RPM, 48 KW turning drive 161 pos. ATC, Renishaw touch probing, chip conveyor, mist collector, twin pallet changer, aux. tooling storage rack, S/N 123631

CNC LATHES

  • LODGE & SHIPLEY MDL. 1540U SLANT BED, G.E. 1050 CNC control, 12 pos. vert. turret, tailstock, approx. 96″ dist. btn. centers, 15″ dia. 3-jaw chuck, 3.5″ spdl. hole, hyd. steadyrest on independent slide, chip conveyor, S/N 50789

CNC HOLLOW SPINDLE LATHES

  • (2) LODGE & SHIPLEY MDL. PROFITURN 40, rebuilt & retrofitted 2015 w/Fanuc 0iTD CNC control, 34-1/2″ sw. over bed & carriage wings, 20″ sw. over crosslide, spds: 6-650 RPM in (3) ranges, 12-1/2″ spdl. hole, 14′ dist. btn. centers, 4 pos. sq. turning turret, 12 pos. hex boring turret, 45 KW main spdl. drive motor, front & rear 28″ dia. 4-jaw chucks, outboard work suppt. rest w/pneu. lift, roller jaw steadyrest, pwr. tailstock, additional control axis for customized tooling, full length chip conveyor, S/N 50786, S/N 50938 (Auctioneers Note: S/N 50938 – is 90+% finished on rebuilt & retrofit. The bid for finishing this machine will be available at time of inspection)
  • (2) LODGE & SHIPLEY MDL. PROFITURN 40, Fanuc 18iT CNC control, 34-1/2″ sw. over bed & carriage wings, 20″ sw. over crosslide, spds: 6-650 RPM in (3) ranges, 12-1/2″ spdl. bore, 14′ dist. btn. centers, 8 pos. sq. turning turret, 12 pos. hex boring turret, interchangeable 4 pos. turning turret & 6 pos. boring turret, 37 KW main spdl. drive motor, front & rear 32″ dia. 4-jaw hollow spdl. chucks, outboard work suppt. rest w/pneu. lift, chip conveyor, roller jaw steadyrest, pwr. tailstock, S/N 50937, S/N 50939
  • LODGE & SHIPLEY MDL. PROFITURN 40, G.E. 1050 CNC control, Fanuc Powermate sgl. axis CNC control for tooling use, outboard roller rest w/airlift, S/N 50940
  • LODGE & SHIPLEY MDL. PROFITURN 40, G.E. 1050 CNC control, interchangeable turrets, outboard bar suppt w/air height adj., S/N 50979 k)
  • GANESH 44″ X 120″ MDL. GTD-44120CNC, new 4/2013, Fanuc 0iTD CNC control, 12 pos. vert. turning turret, 39-1/2″ dia. 4-jaw front chuck, 24-1/2″ dia. 4-jaw rear chuck, 12-1/2″ spdl. hole, spds: 7-350 RPM, in (4) gear ranges, 30 KW spdl. drive motor, pwr. travel tailstock, (2) roller jaw steadyrests, H.D. boring attach., elec. enclosure chiller, S/N 13074

HOLLOW SPINDLE LATHES

  • LODGE & SHIPLEY MDL. POWERTURN 2XE-3220, 34-1/2″ sw. over carriage, 28″ sw. over crosslide, 20′ dist. btn. centers, 12-1/2″ dia. spdl. hole, front & rear 28″ dia. 4-jaw chucks, variable spdl. spds: 0-900 RPM, 50 HP DC variable spd. drive, roller jaw steadyrest, 4-way rapid traverse, S/N 50592
  • KINGSTON MDL. OIL COUNTRY 30, 12-1/2″ spdl. hole, front & rear 24″ dia. 4-jaw chucks, 10′ dist. btn. centers, 30″ sw. over bed, 4-way rapid traverse, spds: 5-300 RPM, inch/metric thdng., S/N N.A.

CNC HOLLOW SPINDLE CHUCKER

  • LODGE & SHIPLEY MDL. PROFITURN 40, Fanuc 0i CNC control, 14-3/4″ spdl. bore, 34-1/2″ sw. over bed & carriage wings, 20″ sw. over crosslide, 6 pos. horiz. boring turret, approx. 60″ Z-axis travel, S/N N.A.

ENGINE LATHE

  • MORI SEIKI 24-1/2″ X 120″ MDL. MH3000, 3.5″ spdl. hole, spds: 27-1235 RPM, taper attach., (2) steadyrests, S/N 4358

VERTICAL MACHINING CENTERS

  • BROWN & SHARPE MDL. SYSTEM 2000VC 4-AXIS, retrofitted w/Fanuc 18i-M CNC control, 30” x 81” table, CAT-50 spdl. taper, 40 pos. ATC, Troyke Mdl. 01-20-AB 4th axis rotary table w/10-1/8″ dia. thru hole & Atlas 23-1/2″ dia. 4-jaw chuck, S/N 517-1-234
  • BROWN & SHARPE MDL. SYSTEM 2000VC 4-AXIS, retrofitted w/Fanuc 0i CNC control, 30” x 81” table, Troyke NC30-A-360 CNC rotary table w/16″ spdl. hole, 32″ dia. 4-jaw chuck, 40 pos. ATC, CAT-50 spdl. taper, S/N 517-3-307
  • (3) BROWN & SHARPE MDL. SYSTEM 2000VC 4-AXIS, G.E. 1050 CNC control, 30” x 81” table, 40 pos. ATC, CAT-50 spdl. taper, S/N 517-3-361 equipped w/ Troyke 20″ rotary table w/9-1/2″ thru hole, 24″ 4-jaw independent chuck, S/N 517-31-398 equipped w/ Troyke 20″ 4th axis rotary table w/10.2″ hole, 24″ 4-jaw chuck, S/N 517-31-387 equipped w/ Troyke 20″ CNC rotary table w/10.2″ spdl. hole, 24″ dia. 4-jaw chuck,
  • BROWN & SHARPE MDL. SYSTEM 1500VC, S/N 517-3-363 (parts use only)

SONIC BORING SYSTEM

  •  (4) DEEP BORE INTERNAL TURNING BORING BARS w/independent servo feed for internal grooving inside drill collars

VERTICAL TURRET MILL

  •  ALLIANT, 9″ x 42″ table, variable spds: 60-4500 RPM, long. pwr. feed, 2-axis D.R.O., S/N 9041442

TABLE TYPE HORIZONTAL BORING MILLS

  • GIDDINGS & LEWIS MDL. 350, 5″ main spdl., 2-1/2″ aux. spdl., main spdl. spds: 8.5-500 RPM, aux. spdl. spds: 34-2000 RPM, 2-axis D.R.O., 48″ x 74″ table, approx. 60″ cross, vert. & long. travels, outboard suppt., S/N 5946
  • LUCAS 4″, Sony Magnascale D.R.O., push button motions, approx. 48″ vert. travel, 40″ x 74″ table, 60″ cross travel, approx. 84″ long. travel, S/N 4600206

HORIZONTAL BANDSAWS

  • HEM MDL. H160A-DC, new 1996, 2″ blade size, 15 HP motor, variable blade spd., dbl. column design, auto. feed unit w/dual hyd. vises, 5′ H.D. output table, bundle clamp, Cutwatcher system, S/N 525296
  • HEM MDL. 1200LAR, auto. index feed, S/N 67878

TRAVELLING COLUMN STRAIGHTENING PRESS

  • DAKE APPROX. 150 T. CAP., 30″ dist. btn. columns, approx. 16′ column travel, 24″W. x 19′-7″L. bed, (2) roller & (2) stationary V block rests

HORIZONTAL HONING MACHINE

  • BARNES MDL. 6, approx. 16′ max. stroke, 18″W. x approx. 16’L. fixture table w/ (2) roller chain rests & steadyrest, Barnes paper filter magnetic coolant system, 5 HP hone drive, (2) 16′ hone mandrels, wide array of honing heads up to 7-1/2″ dia., assorted hone tooling S/N 9028

ROTARY SCREW AIR COMPRESSOR

  • FIAC MDL. AIR BLOCK 50, new 2006, 50 HP motor, w/Quincy refrigerated dryer, 240 gal. vert. air receiver, S/N BF923378

AUTOMATIC TOOL DISPENSING CRIB

  • AUTOCRIB MDL. VK500, (89) bins, 15-station aux. rotary carousal, S/N N.A.

MISCELLANEOUS MACHINES

  • WOLDMANN & WEIGLTAP DISINTEGRATOR, roller base, S/N N.A.
  • CUTTER MASTER CUTTER SHARPENING MACHINE, air bearing fixture, tilting spdl., S/N N.A.

PRECISION INSTRUMENTS

  • (19) API THREAD & PLUG WORKING GAUGES and (18) RING GAUGES – most by PMC Lone Star from 2″ to 8-5/8″; SMALL DIA. THREAD PLUG GAUGES; END MEASURING RODS; GAUGE BLOCKS; STANDARD & BLADE TYPE MICROMETERS; AIR TRIMICROMETERS; FOWLER ELECTRONIC DIGITAL INTERNAL BORE INDICATORS; OVER (40) LARGE DIA. PRECISION RING GAUGES; VERNIER CALIPERS; 0 TO 12″ MICROMETER SETS

QUALITY CONTROL DEPARTMENT

  • NIKON MDL. H16E-II HORIZONTAL BEAM COMPARATOR, 10X lens, surface reflection, S/N 0211/1108; TESA HITE MDL. 700 ELECTRONIC HEIGHT GAUGE, Item No. 007.30044, S/N 3L-306-02; PRECISION GRANITE SURFACE PLATE, 36″ x 48″ x 6″ thk., fabricated stand; L.K. MDL.LY90 CANTILEVER ARM LAYOUT COORDINATE MACHINE, new 2004, Renishaw PH10M probe head, (arm only – no table) S/N LY90/58890/04

PRECISION MACHINE ACCESSORIES

  • LARGE DIA. LIVE CENTERS; V BLOCKS; BORING BLOCKS; ASSORTED 3-JAW & 4-JAW CHUCKS; TOOLPOST GRINDING ATTACHMENT; ALORIS QUICK CHANGE TOOLPOSTS & HOLDERS; MESSMA KELCH ROBOT TYPE KALIMAT 500-2M TOOL PRESETTER, new 1995, comparator head & #50 taper sleeve, S/N 650; (over 400) CAT-50 TAPER TOOLHOLDERS – most by Lindex, including collet style holders, endmill holders, extended length endmill holders, extended length collet holders & much more.

MISCELLANEOUS SHOP AND WAREHOUSE EQUIPMENT

  • DRILLS; TAPS; REAMERS; ROUGHING & FINISHING ENDMILLS in 2-flute, 4-flute & 6-flute sizes; INDEXABLE TURNING TOOLS; INDEXABLE BORING BAR HEADS; CARBIDE INSERTS; HUGE ASSORTMENT OF H.D. INTERCHANGEABLE HEAD BORING BARS up to 3-1/2″; (2) 20″ DIA. POWER ROTARY TABLES w/10.2″ holes & DC variable drive; LUCAS 48″ MANUAL ROTARY TABLE; (2) MIST COLLECTORS

FORKLIFT

  • HYSTER 15,000 LB. CAP. MDL. S150A, LPG pwrd., 15,000 lb. cap. @ 24″ L.C., 159.5″ max. lift, 48″ forks, large cushion tires, S/N A024D047008

ADJUSTABLE PORTABLE GANTRY CRANE

  • ½ T. CAP. , adj. ht. under hook to approx. 12′, 16′ overall beam length

FREE STANDING PEDESTAL JIB CRANES

  • (4) 2 T. CAP. X 14′ REACH, approx. 10′ ht. under hook
  • (2) 2 T. CAP. X 14′ REACH, approx. 9′ ht. under hook
  • 2 T. CAP. X 13′ REACH, approx. 8′ ht. under hook
  • 1 T. CAP. X 16′ REACH, approx. 9′ ht. under hook
  • 1 T. CAP. X 14′ REACH, approx. 10′ ht. under hook
  • (2) 1 T. CAP. X 14′ REACH, approx. 9′ ht. under hook
  • ½ T. CAP. X 13′ REACH, approx. 9′ ht. under hook
  • ½ T. CAP. X 8′ REACH, approx. 6′ ht. under hook

MATERIAL HANDLING EQUIPMENT

  • (5) ROLLER DRAWER TOOL CABINETS; SEVERAL FLAMMABLE STORAGE CABINETS; EXTENDABLE FORKLIFT BOOM; (4) GALBREATH 1 CU. YD. DUMPING HOPPERS; GALBREATH ½ CU. YD. SELF-DUMPING HOPPER on casters; HUOT TOOL CADDY CARTS w/casters for Galbreath ½ cu. yd. self-dumping hoppers; DIGITAL PLATFORM SCALE; TOLEDO VERTEX 60″ SQ. PLATEN w/I.Q. Plus 355 D.R.O. box; WIDE ASSORTMENT OF H.D. FABRICATED STEEL HORSES & SUPPORT STANDS; ELECTRIC CHAIN HOISTS; OIL STORAGE CARTS; TOOLHOLDER STANDS



Auction Location
7632 Cherokee Drive, Katy, TX 75081 Get Directions
