Prestige Equipment is the world's leading provider of 40" x 393" Waldrich Roll Grinder & machine tools & fabricating equipment. Take a look at our wide selection of new and used Roll Grinders for sale.
Product Specifications
Features:
✓
Crowning Capability
✓
(9) Small Work Rests
✓
(2) Large Work Rests
✓
29" Face Plate
✓
21" 4-Jaw Chuck
✓
Sliding Steel Way Covers on Bed
✓
Barnes Coolant and Filtration System
✓
Magnetic Chip Separator
Product Specifications
SPECIFICATIONS:
Maximum Work Diameter
40"
Minimum Work Diameter
.75"
Distance Between Centers
393"
Wheel Size (Diameter x Width)
30" x 4"
Wheel Hole Diameter
12"
Workhead Drive Motor
29.48 HP
Headstock Speed Range
10 to 100 RPM
Weight Between Centers
10 Tons
Normal Infeed
0.0004 - 0.028
Carriage Feed
2.375 - 118 IPM
Equipped With:
Crowning Capability
(9) Small Work Rests
(2) Large Work Rests
29" Face Plate
21" 4-Jaw Chuck
Sliding Steel Way Covers on Bed
Barnes Coolant and Filtration System
Magnetic Chip Separator
Features:
✓
Crowning Capability
✓
(9) Small Work Rests
✓
(2) Large Work Rests
✓
29" Face Plate
✓
21" 4-Jaw Chuck
✓
Sliding Steel Way Covers on Bed
✓
Barnes Coolant and Filtration System
✓
Magnetic Chip Separator
